济南通风管道安装风管应该如何相连?

来源:http://www.jntfgd.com 日期:2022-04-13 发布人:jntfgd

通风管道是连接风机与外部空气的管道,它的安装十分重要,会影响到风机的使用效率,因此在安装时要保证风机与管道、管道与管道之间连接完整,这样才能保证风机的正常使用,在连接时要注意做好固定,防止后期使用时出现影响排烟的问题,那么在通风管道安装风管应该如何相连呢?有哪几种方式?接下来我们和通风管道厂家一起了解下吧。
The ventilation duct is the duct connecting the fan and the external air. Its installation is very important and will affect the service efficiency of the fan. Therefore, during installation, it is necessary to ensure the complete connection between the fan and the pipe and between the pipe and the pipe, so as to ensure the normal use of the fan. Pay attention to fixation during connection to prevent problems affecting smoke exhaust during later use. How should the air duct be connected when installing the ventilation duct? How many ways? Next, let's get to know with the ventilation duct manufacturer.
1、卡箍连接:主要用于连接钢板圆形通风管道和螺旋风管。首先,每个管段的两端都绕成筋,一端小。安装时,将口沿气流方向插入,将两端的带子在外面用钢箍拧紧,将耳环中间的螺栓固定并拧紧。这个过程需要注意,不应影响油管的正常使用。安装过程中确保空气管路紧密,以达到良好的效果。
1. Clamp connection: mainly used to connect steel plate circular ventilation duct and spiral air duct. First, both ends of each pipe section are wound into ribs, and one end is small. During installation, insert the mouth along the air flow direction, tighten the belts at both ends with steel hoops, and fix and tighten the bolts in the middle of the earrings. Attention shall be paid to this process, which shall not affect the normal use of oil pipe. During installation, ensure that the air pipeline is tight to achieve good results.
2、插入式连接:主要用于矩形或圆形管道连接。制作好连接管后,从两侧插入管内,用铆钉固定。这种固定方式的使用比较有限,但是安装方式比较简单易懂,可以节省一些施工时间,从而保证风管的正常使用。
2. Plug in connection: mainly used for rectangular or circular pipe connection. After making the connecting pipe, insert it into the pipe from both sides and fix it with rivets. The use of this fixed method is relatively limited, but the installation method is relatively simple and easy to understand, which can save some construction time and ensure the normal use of air duct.
3、插入式连接:主要用于矩形管连接。安装通风管道时,可在管道两端插入不同形状的嵌件,使其紧凑。
3. Plug in connection: mainly used for rectangular pipe connection. When installing the ventilation duct, insert inserts of different shapes at both ends of the duct to make it compact.
4、软管式连接:主要用于连接管道和零件(如散热器、静压箱侧送风口等)。安装时,将软管两端插入连接管内,用专用软卡固定软管。独特设计的过滤介质不仅具有良好的通风性能,而且提高了更好的过滤面积的长使用寿命和除尘效率。
4. Hose connection: mainly used to connect pipes and parts (such as radiator, plenum side air supply outlet, etc.). During installation, insert both ends of the hose into the connecting pipe and fix the hose with a special soft clip. The uniquely designed filter medium not only has good ventilation performance, but also improves the better filter area, long service life and dust removal efficiency.
以上是通风管道与空气管的各种连接方式。安装时应注意不要影响风管质量,保证连接过程的稳定性。另外要注意风管可以安装多少种方式,但是不同的连接方式需要注意不同的内容,需要具体的操作才能保证风管的正常安装。
The above are various connection modes of ventilation pipe and air pipe. During installation, pay attention not to affect the quality of air duct and ensure the stability of connection process. In addition, pay attention to how many ways the air duct can be installed, but different connection methods need to pay attention to different contents, and specific operations are required to ensure the normal installation of the air duct.
以上就是为大家介绍的有关山东通风管道钱的作用的详细介绍,希望对您有所帮助.如果您有什么疑问的话,欢迎联系我们.我们将以的态度,为您提供服务http://www.jntfgd.com
The above is a detailed introduction to the role of Shandong ventilation pipe money. I hope it will be helpful to you If you have any questions, please contact us We will provide you with professional service http://www.jntfgd.com
